Electrical Specifications | ||
Type | Specifications | |
Frequency Range | 32.768KHz~60.0MHz | |
Output Type | CMOS/TTL | |
Oscillation Mode | Fundamental/3rd Overtone | |
Supply Voltage | 1.8V 2.5V | 2.8V 3.3V 5V |
Output Load | 15pF, or specify | |
Frequency Stability | ±20ppm;±30ppm | |
Operating Temperature Range | -20℃ ~ +75℃, -40℃ ~ +85℃ | |
Storage Temperature Range | -55℃ ~ +125℃ | |
Voltage vol(max)/Voh(min) | 0.1 VDD/ 0.9VDD | |
Rise(Tr)/Fall(Tf) Time | 8 ns Max. | |
Supply Current | 15 mA Max. | |
Symmetry | 45~55% | |
Start-up Time | 5 ms Max. | |
Phase Jitter(12KHz~20MHz) | 1ps Max. | |
Aging(Ta=25℃) | ±3ppm/Year Max. | |
Please consult our sales representatives for more information. | ||
